Key Specifications

LED Indicators

Power LED

1 x LED (Green)

Input LED

1 x LED (Green)

Video Output LEDs

10 x LED (Green)

Video Input

Input Interface

1 x HDMI Type A Female (Black)

Input Impedance

100 Ω

Max Input Distance

5 m (at 4K resolution)

Video Output

Output Interfaces

10 x HDMI Type A Female (Black)

Output Impedance

100 Ω

Max Output Distance

10 m (at 4K resolution)

Video

Max Data Rate

10.2 Gbps (3.4 Gbps Per Lane)

Max Pixel Clock

340 MHz

Compliance

HDMI (3D, Deep Color, 4K)
HDCP 1.4 Compatible

Max Resolution

Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0)
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)

Control

RS-232

1 x DB-9 Female (Black)
Baud Rate: 19200
Data Bits: 8
Stop Bits: 1
Parity: No
Flow Control: No

EDID Settings

1 x EDID Switch
Modes: Default (1080p) / Port 1 / Auto

Connectors

Power Connector

1 x DC Jack

USB Port

1 x Micro USB (Firmware Upgrade)

Power Consumption

DC5V: 4.34W / 20BTU/h

Environmental

Operating Temperature

0 - 40°C

Storage Temperature

-20 - 60°C

Humidity

0 - 80% RH (Non-Condensing)

Physical Properties

Housing

Metal

Weight

2.10 kg (4.63 lb)

Dimensions

43.72 x 15.78 x 4.40 cm
(17.21 x 6.21 x 1.73 in.)

Carton Lot

3 pcs
