Key Specifications

Input Type

Electronically balance/unbalanced, RF filtered

Input Impedance

Balance 50K, Unbalanced 25K

Output Impedance

Balance 120 ohm, Unbalanced 60 ohm

Sidechain

1/4" TRS Normalled: Ring-Output (send); tip-Input (return)

Sidechain Impedance

Tip=10K ohm (input), Ring=2Kohm (Output)

Frequency Response

20Hz to 20kHz

THD

<0.04%

Compressor Threshold Range

-40dBu to +20dBu

Compressor Ratio

Variable; 1:1 to Infinity:1; 60dB Max Compression

Compressor Attack Time

Variable program-dependent; 3ms to 340ms

Compressor Release Time

Variable program-dependent; 200dB/sec to 3dB/sec

Expander/Gate Threshold Range

OFF to +15dBu

Expander /Gate Ratio

10:1

Expander Attack Time

<500ps (from Max Depth)

Expander Release Time

Adjustable, 30ms to 3sec

Limiter Treshold Range

0dBu to +20dBu

Operating Voltage

220V 50Hz-60Hz

Dimension (HxWxD)

4.4(H) x 48(W) x 17.5(D)cm

Net Weight

2.2Kg
