Key Specifications

Video Input

Interfaces

1 x HDMI Type A Female (Black)

Impedance

100 Ω

Max. Distance

3m @3840x2160@30Hz (4:4:4)

Video Output

Interfaces

2 x HDMI Type A Female (Black)

Impedance

100 Ω

Max. Distance

15m @3840x2160@30Hz (4:4:4)

Video

Max. Data Rate

10.2 Gbps (3.4 Gbps Per Lane)

Max. Pixel Clock

340 MHz

Compliance

HDMI (3D, Deep Color, 4K)
HDCP Compatible

Max. Resolution

Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0)
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)

Audio

Input

1 x HDMI Type A Female (Black)

Output

2 x HDMI Type A Female (Black)

Connectors

Power

1 x DC Jack

Environmental

Operating Temperature

0–50 °C

Storage Temperature

-20 – 60 °C

Humidity

0 – 80% RH, Non-Condensing

Physical Properties

Housing

Metal

Weight

0.31 kg (0.68 lb)

Dimensions (L x W x H)

12.50 x 8.00 x 2.50 cm
(4.92 x 3.15 x 0.98 in.)

Power

Power Consumption

DC 5.3V: 3.12W : 15BTU/h

Note

Additional Information

For rack mount products, standard physical dimensions are expressed using L x W x H format.
