Key Specifications

Video I/O

Input: 1x BNC (12G-SDI) Female
Output: 1x BNC (12G-SDI) Female

Audio I/O

Input: 1x XLR 5-Pin Analog Female
Output: 1x XLR 5-Pin Analog Female

Video Resolution

SDI Input/Output (4:2:2 YUV)
4096 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
2048 x 1080 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/60 fps
1920 x 1080PsF at 25/29.97/30 fps
1920 x 1080i at 25/29.97/30 fps
1280 x 720 at 50/59.94/60 fps
720 x 480i at 59.94 fps
720 x 576i at 50 fps

Wireless

No

OS Compatibility

macOS 13 or Later
Windows 10 to 11

Inputs / Outputs

Video I/O

Input: 1x BNC (12G-SDI) Female
Output: 1x BNC (12G-SDI) Female

Audio I/O

Input: 1x XLR 5-Pin Analog Female
Output: 1x XLR 5-Pin Analog Female

Other I/O

Input/Output: 1x RJ45 (10 GbE)
Input: 1x USB-C (Firmware)

Expansion Slots

1x SFP Slot

Format Support

Video Resolution

SDI Input/Output (4:2:2 YUV)
4096 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
2048 x 1080 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/60 fps
1920 x 1080PsF at 25/29.97/30 fps
1920 x 1080i at 25/29.97/30 fps
1280 x 720 at 50/59.94/60 fps
720 x 480i at 59.94 fps
720 x 576i at 50 fps

Embedded Audio

LAN (RJ45) / SDI

Standards

Video Standard Compliance

SMPTE ST-2110

HDCP Support

No

HDR Support

Yes

Hardware

Wireless

No

OS Compatibility

macOS 13 or Later
Windows 10 to 11

Power

Power I/O

1x Barrel (12 to 16 VDC) Input

PoE Support

Yes: PoE++ 802.3bt

Power Consumption

Device: 12 to 16 VDC (18 W)

General

Operating Conditions

41 to 104°F / 5 to 40°C up to 90% Humidity

Storage Conditions

-4 to 113°F / -20 to 45°C up to 90% Humidity

Dimensions

5.75 x 2.91 x 1.34" / 14.61 x 7.39 x 3.4 cm

Packaging Info

Package Weight

1.505 lb

Box Dimensions (L × W × H)

10.4 x 5.3 x 1.3"
