Key Specifications

Input Type

Electronically balance/unbalanced, RF filtered

Input Impedance

Balance 40KΩ, Unbalanced 20KΩ

Output Impedance

Balance 100 ohm, Unbalanced 50 ohm

Bandwidth

20Hz - 20KHz

Frequency Response

10Hz to 50KHz

S/N ratio

≥93dB

THD

≤-90dB, 20Hz to 20KHz

Interchannel Crosstalk

≤88dB

Low cut Switch

50Hz 12dB/octave Bessel high-pass filter

Range Switch

+/-6 dB or +/-12dB slider boost/cut range

Bypass Switch

Bypasses thru signal path

Dynamic Range

≥108dB

Operating Voltage

220V 50-60Hz

Dimension (HxWxD)

4.4(H) x 48(W) x 15(D)cm

Net Weight

2Kg
