Key Specifications

Input Type

Electronically balance/unbalanced, RF filtered

Input Impedance

Balance 50KΩ, Unbalanced 25KΩ

Output Impedance

Balance 60 ohm, Unbalanced 30 ohm

Bandwidth

20Hz - 20KHz

Frequency Response

3Hz to 80KHz

S/N Ratio

≥94dB (low), ≥93dB (mid), ≥90dB (High) output

THD

≤0.004%

Interchannel Crosstalk

≤81dB

Low Cut Switch

40Hz 12dB/octave Bessel high-pass filter,
one switch per channel

Phase Invert Switch

Inverts the phase at the output, one switch per output

Mode Switch

Selects stereo / mono 2 / 3 / 4-way operation

Dynamic Range

≥108dB

Operating Voltage

220V 50-60Hz

Dimension (HxWxD)

4.4(H) x 48(W) x 17.5(D) cm

Net Weight

1.8 Kg
