Key Specifications

Video Input Interface

1 x HDMI Type A Female (Black)

Input Impedance

100 Ω

Max Input Distance

1.8 m

Video Output Interfaces

1 x HDMI Type A Female (Black) - Local Output
4 x RJ-45 Female

Output Impedance

100 Ω

Max Data Rate

10.2 Gbps (3.4 Gbps Per Lane)

Max Pixel Clock

340 MHz

Compliance

HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
HDBaseT Compatible

Max Resolution

Up to 4096 × 2160 / 3840 × 2160 @ 60Hz (4:2:0)
4096 × 2160 / 3840 × 2160 @ 30Hz (4:4:4)
(Depends on connected receiver)

Max Distance

Up to 100 m (Depends on connected receiver)

Audio

Audio Input

1 x HDMI Type A Female (Black)

Audio Output

1 x HDMI Type A Female (Black)

Control

RS-232

Connector: 1 x DB-9 Female (Black)
Pin2 = Tx, Pin3 = Rx, Pin5 = Gnd
Baud Rate: 19200
Data Bits: 8
Stop Bits: 1
Parity: No
Flow Control: No

EDID Settings

Default / Port 1 / Auto / Learn

Connectors

Power

1 x 3-Prong AC Socket (Black)

Power Consumption

AC110V: 18.2W (85 BTU/h)
AC220V: 18.2W (85 BTU/h)

Environmental

Operating Temperature

0 - 50°C

Storage Temperature

-20 - 60°C

Humidity

0 - 80% RH (Non-Condensing)

Physical Properties

Housing

Metal

Weight

3.47 kg (7.64 lb)

Dimensions

43.24 x 26.11 x 4.40 cm (17.02 x 10.28 x 1.73 in.)

Carton Lot

1 pc
