Key Specifications

Switches

DIP Switch

1 x Auto Switch On/Off

Video Input

Interfaces

4 x HDMI Type A Female (Black)

Impedance

100 Ohms

Maximum Distance

9.8' / 3 m

Video Output

Interfaces

1 x HDMI Type A Female (Black)

Impedance

100 Ohms

Maximum Distance

9.8' / 3 m

Video

Maximum Data Rate

18 Gb/s (6 Gb/s per Lane)

Maximum Pixel Clock

600 MHz

Compliance

HDMI 2.0 (3D, Deep Color, 4K)
HDCP 2.2
Consumer Electronics Control (CEC)

Maximum Resolution

4096 x 2160 / 3840 x 2160 at 60 Hz (4:4:4)

Control

RS-232

Connector: 1 x DB-9 Female (Black)
Baud Rate: 19200
Data Bits: 8
Stop Bits: 1
Parity: No
Flow Control: No

IR

1 x Mini Stereo Jack Female (Black)
1 x IR Receiver

Power

Connectors

1 x DC Jack, Locking

Power Consumption

At 5 VDC: 5 W

Environmental

Operating Temperature

32 to 104°F / 0 to 40°C

Storage Temperature

-4 to 140°F / -20 to 60°C

Humidity

0 to 80% RH, Non-Condensing

Physical Properties

Housing

Metal

Dimensions

7.87 x 3.23 x 0.98" / 20.00 x 8.21 x 2.50 cm

Weight

1.04 lb / 0.47 kg

Packaging Info

Package Weight

1.715 lb

Box Dimensions (L x W x H)

10 x 7 x 2.2"
