Key Specifications

Microphone Type

Large Diaphragm

Polar Pattern

Cardioid

Element Type

Condenser

Sound Field

Mono

Diaphragm

1" / 25.4 mm

Orientation

Side Address

Controls

Pad, Low Cut / HPF

Pad

-10 dB
-20 dB

Filter & EQ

Low-Cut Filter: 80 Hz, 6 dB/Octave
160 Hz, 6 dB/Octave

Circuitry

Solid-State

Performance

Frequency Response

20 Hz to 20 kHz

Maximum SPL

137 dB (0.5% THD)
157 dB (0.5% THD, with Pad)

Dynamic Range

128 dB (Phantom Power, without Pad)
148 dB (Phantom Power, with Pad)

Equivalent Noise Level

9 dB (A-Weighted, Phantom Power)

Connectivity

Analog Output

1x XLR 3-Pin Male

Power

Power Source

Phantom Power

Operating Voltage

48 V (Phantom Power)

Physical

Color

Black

Mounting Thread Size

5/8"-27 Female (3/8"-16 Female with Included Adapter)

Dimensions

ø: 1.1 x W: 2.32 x L: 5.75"
ø: 2.8 x W: 5.89 x L: 14.61 cm

Weight

9.9 oz / 280 g

Packaging Info

Package Weight

7.675 lb

Box Dimensions (L × W × H)

13.9 x 11.3 x 5.7"
