Key Specifications

Connectivity

Wireless Network

IEEE 802.11 b/g/n 2.4 GHz

Ethernet

1 × 10/100 Mbps RJ45

Bluetooth

Bluetooth 5.0

USB Host

USB 2.0

General

Bluetooth Range

15 m

Power Input

5 V / 1 A via Micro USB

Frequency Response

20 Hz – 20 kHz

Signal-to-Noise Ratio (SNR)

91 dB

Total Harmonic Distortion (THD)

0.03%

Supported Music Formats

FLAC, MP3, AAC, AAC+, ALAC, APE, WAV

Sample Rate Decoding

Up to 24-bit / 192 kHz

Supported Protocols

AirPlay, DLNA, UPnP, Spotify Connect, Qplay

Inputs & Outputs

Audio Output

1 × 3.5 mm Analog Mini Jack

Audio Input

1 × 3.5 mm Analog Mini Jack, Micro USB

Mechanical Specifications

Product Code

47245

Dimensions (W × H × D)

116 × 23 × 64 mm (4.56 × 0.90 × 2.51 in)

Net Weight

0.20 kg (0.44 lb)

LED Indicators

NET

White – Power On / Wi-Fi Mode

BT

Blue – Bluetooth Mode

USB

Red – USB Mode

AUX

Green – Line Input Mode
