Key Specifications

Conductor

Size

23 AWG

Stranding

Solid

Material

BC - Bare Copper

No. of Pairs

4

Insulation

Material

PO - Polyolefin

Color Code

Blue & White with Blue Markings, Orange & White with Orange Markings, Green & White with Green Markings, Brown & White with Brown Markings

Cable Core

Description

Overall Cabling Fillers

Outer Shield

Shield Type

Tape

Material

Bi-Laminate (Alum+Poly)

Coverage

100%

Outer Jacket

Material

PVC - Polyvinyl Chloride

Nom. Diameter

7.5 mm (0.30 in)

Ripcord

Yes

Electricals

Max. Conductor DCR

93.8 Ohm/km (28.6 Ohm/1000ft)

Max. Mutual Capacitance

56 pF/m (17 pF/ft)

Max. Capacitance Unbalance

330 pF/100m

Nom. Characteristic Impedance

100 Ohm

Delay

Max. Delay

538 ns/100m

Max. Delay Skew

45 ns/100m

Nom. Velocity of Prop.

70%
