Key Specifications

Conductor

Size

24

Stranding

Solid

Material

BC - Bare Copper

No. of Pairs

4

Insulation

Material

PE - Polyethylene

Nom. Insulation Diameter

0.97 mm (0.038 in)

Color Code

Blue & White with Blue Stripe
Orange & White with Orange Stripe
Green & White with Green Stripe
Brown & White with Brown Stripe

Outer Jacket

Material

PVC - Polyvinyl Chloride

Nom. Diameter

5.8 mm (0.23 in)

Ripcord

YesElectricals

Max. Conductor DCR

93.8 Ohm/km (28.6 Ohm/1000ft)

Max. Mutual Capacitance

56 pF/m (17 pF/ft)

Max. Capacitance Unbalance

330 pF/100m

Nom. Characteristic Impedance

100 Ohm

Delay

Frequency

100 MHz

Max. Delay

538 ns/100m

Max. Delay Skew

45 ns/100m

Nom. Velocity of Prop.

70%

Notes

Jacket sequentially marked
