Key Specifications

LED Indicators

Input LED

1 x LED (Green)

Video Output LEDs

8 x LED (Green)

Power LED

1 x LED (Green)

Video Input

Input Interface

1 x HDMI Type A Female (Black)

Input Impedance

100 Ω

Max Input Distance

5 m at 4K@60Hz (4:4:4)

Video Output

Output Interfaces

8 x HDMI Type A Female (Black)

Output Impedance

100 Ω

Max Output Distance

5 m at 4K@60Hz (4:4:4)

Video

Max Data Rate

18 Gbps (6 Gbps Per Lane)

Max Pixel Clock

600 MHz

Compliance

HDMI 2.0 (3D, Deep Color, 4K)
HDCP 2.2

Max Resolution

Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Control

RS-232

1 x DB-9 Female (Black)
Baud Rate: 19200
Data Bits: 8
Stop Bits: 1
Parity: No
Flow Control: No

EDID Settings

1 x EDID Slide Switch
Modes: Port 1 / Default / Auto / Switch

Connectors

Power Connector

1 x DC Jack

Power Consumption

DC5V: 11.95W / 56BTU/h

Environmental

Operating Temperature

0 - 40°C

Storage Temperature

-20 - 60°C

Humidity

0 - 80% RH (Non-Condensing)

Physical Properties

Housing

Metal

Weight

2.18 kg (4.8 lb)

Dimensions

43.72 x 15.78 x 4.40 cm
(17.21 x 6.21 x 1.73 in.)

Carton Lot

3 pcs
