Key Specifications

Switches

DIP Switch

1 x Auto Switch On/Off

Video Input

Interfaces

8 x HDMI Type A Female (Black)

Impedance

100 Ohms

Maximum Distance

9.8' / 3 m

Video Output

Interfaces

1 x HDMI Type A Female (Black)

Impedance

100 Ohms

Maximum Distance

9.8' / 3 m

Video

Maximum Data Rate

18 Gb/s (6 Gb/s per Lane)

Maximum Pixel Clock

600 MHz

Compliance

HDMI 2.0 (3D, Deep Color)
HDCP 2.2
Consumer Electronics Control (CEC)

Maximum Resolution

4096 x 2160 / 3840 x 2160 at 60 Hz (4:4:4)

Maximum Distance

9.8' / 3 m

Control

RS-232

Connector: 1 x DB-9 Female (Black)
Baud Rate: 19200
Data Bits: 8
Stop Bits: 1
Parity: No
Flow Control: No

IR

1 x Mini Stereo Jack Female (Black)

Power

Power Connectors

1 x DC Jack, Locking

Power Consumption

At 5.3 VDC: 3.73 W, 17 BTU

Environmental

Operating Temperature

32 to 104°F / 0 to 40°C

Storage Temperature

-4 to 140°F / -20 to 60°C

Humidity

0 to 80% RH, Non-Condensing

Physical Properties

Housing

Metal

Rackmount Space

1 RU

Dimensions

17.21 x 6.23 x 1.73" / 43.72 x 15.83 x 4.40 cm

Weight

4.71 lb / 2.14 kg

Packaging Info

Package Weight

6.275 lb

Box Dimensions (L x W x H)

21.3 x 9.6 x 5.1"
