Key Specifications

Drivers

4 in (100 mm), Full-range Driver

Performance

• Frequency Range: 60 Hz – 18 kHz
• Sensitivity: 93 dB (1 kHz – 8 kHz)
• Coverage Angle: 130° conical
• Maximum SPL (1m): 101 dB ave. (top 70V/100V tap)

Power & Connectivity

• Power Rating: See transformer taps
• Transformer Taps: 6W, 3W, 1.5W (0.75W at 70V only)
• Input Connectors: Bare wires

Physical & Installation

• Dimensions (Diameter x Depth): 8.1 in (206mm) x 3.5 in (89mm)
• Weight: 2.5 lb (1.2 kg)
• Color: White
• Backcan: No
• Baffle/Rim: Plastic
• Ceiling Cutout Size: 175 mm diameter (6.9 in)
• Plenum Usage: Not intended for use in return air plenums

Accessories

• Included: Sculpted Grille
• Optional: MTC-8124C C-ring, MTC- Rail tile rails
