Key Specifications

Drivers

8 in (200 mm), Full-range Driver

Performance

• Frequency Range: 50 Hz – 16 kHz
• Sensitivity: 97 dB (1 kHz – 8 kHz)
• Coverage Angle: 90° conical
• Maximum SPL (1m): 105 dB (top 70V/100V tap)

Power & Connectivity

• Power Rating: See transformer taps
• Transformer Taps: 6W, 3W, 1.5W (0.75W at 70V only)
• Input Connectors: Bare wires

Physical & Installation

• Dimensions (Diameter x Depth): 11.3 in (287mm) x 4.1 in (105mm)
• Weight: 3 lb (1.4 kg)
• Color: White
• Backcan: No
• Baffle/Rim: Plastic
• Ceiling Cutout Size: 260 mm diameter (10.1 in)
• Plenum Usage: Not intended for use in return air plenums

Accessories

• Included: Sculpted Grille
• Optional: MTC-8124C C-ring, MTC-Rail tile rails
