Key Specifications

Power Source

220 - 240 V, 50/60 Hz

Rated Output

240 W

Power Consumption

48 W (AC operation at 1/8 maximum output without clip)

Frequency Response

50 - 20,000 Hz, ±3 dB

Horn Filter Band

230 - 20,000 Hz, ±3 dB

Distortion

Under 1% at 1 kHz, 1/3 rated power

Input

MIC 1-3: -60 dB*, 600 Ω, balanced, phone jack
AUX 1, 2: -20 dB*, 10 kΩ, unbalanced, RCA pin jack

Output

Speaker out: Balanced (floating), High impedance: 42 Ω (100 V)
Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack

Phantom Power

DC +21 V (MIC 1)

S/N Ratio

Over 60 dB

Tone Control

Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz

Muting

MIC 1: Mutes other input signals by 0 - 30 dB attenuation

Indicator

Power, Peak, Signal

Finish

Panel: ABS resin, black
Case: Steel plate, black

Dimensions

420 (W) × 100.6 (H) × 280.3 (D) mm (16.54" × 3.96" × 11.04")

Weight

4.0 kg (8.88 lb)
