Key Specifications

Wireless Technology

Digital UHF

Max Operating Range

328.1' / 100 m (Line of Sight)

Microphone Type

Handheld with Interchangeable Capsule

Included Capsule

KSM11 Cardioid Condenser

System

RF Frequency Band

417 to 616 MHz (Region Dependent)

Latency

2.0 to 2.9 ms (Selectable)

Encryption

AES 256-Bit

Mobile App Compatible

Yes (ShurePlus Channels)

Transmitters

RF Output Power

2 / 10 / 35 mW (Selectable)

Antenna

Internal Single-Band Helical

Gain Range

-12 to +21 dB (1 dB Steps)

Sync Method

Infrared (IR)

Microphone (KSM11)

Polar Pattern

Cardioid

Frequency Response

50 Hz to 20 kHz

Maximum SPL

151 dB SPL

Power

Battery Type

2x AA or Shure SB900B Rechargeable Li-ion

Battery Life

Alkaline: 8 Hours / SB900B: Up to 9 Hours

Physical

Housing

Cast Aluminum

Dimensions (L x D)

10.1 x 2.0" / 256 x 51 mm

Weight

12 oz / 340 g (without Batteries)

Packaging Info

Package Weight

1.595 lb

Box Dimensions (LxWxH)

13.5 x 4.8 x 3.4"
