Key Specifications

Cabinet Type

Active PA Cabinet

LF Driver

3x 6.5-inch HH designed high performance driver

HF Driver

1-inch compression driver

Frequency Response

55Hz - 20000Hz (-10dB), 60Hz - 18000Hz (-3dB)

Coverage

80° x 80°

Max SPL (1m)

118 dB SPL Continuous, 125 dB SPL Peak

Amplifier & Audio Performance

System Amplifier Power

400W Peak

Amplifier Type

Class A/B

Power Supply

Linear Low Noise Toroidal PSU with switchable mains voltage

Protection

Comprehensive protection and clip free limiting + clip indicator

Mixer, Features & Connectivity

Mixer

Integrated 3 channel mixer

Media Player & Wireless

Onboard media player with Bluetooth 5.0, USB and SD Card, True Stereo Wireless Connectivity

Controls

Channel 1 Level, Channel 2 Level, Bass, Treble, Volume Input

Input Connectors

2x Balanced XLR Connectors with Mic/Line switch, 2x 6.3mm Line Level jack inputs, 1x Stereo 3.5mm Jack input

Output Connectors

1x Balanced XLR Mix Out

Input Impedance

100K Balanced Line, 1K Mic, 10K unbalanced

Signal Indicators

Power, Clip Indicator

Enclosure & Construction

Enclosure Material & Finish

Acoustically optimised 15mm MDF cabinet with heavy duty black vinyl covering and metal corner protectors

Hardware & Mounting

Integrated rear carry pocket handle, powder coated front grille, bottom 35mm pole mount socket

Power Specifications

AC Power Requirements

100V-120V~ OR 220-240V~ 50/60Hz User Switchable

Power Inlet

IEC C14 Inlet Typical

Power Consumption

320W

Dimensions & Weight

Unit Dimensions (H×W×D)

720 x 205 x 230mm (28.3" x 8.1" x 9.1")

Unit Weight

9.7kg (21.4 lbs)

Carton Dimensions (H×W×D)

805 x 285 x 260mm (31.7" x 11.2" x 10.2"), 0.06 M³

Packed Weight

14.9kg (32.8 lbs)
