Key Specifications

Product / Device Type

Short-Throw Laser Phosphor DLP Projector

Projection System / Technology

1-Chip DMD DLP

Native Resolution

Full HD 1080p (1920 x 1080)

Native & Supported Aspect Ratios

Native: 16:9 | Supported: 16:10, 4:3, 1:1

Maximum Brightness

4,000 ANSI Lumens

HDR Support

Yes (HDR10 / Hybrid Log-Gamma)

3D Format Support

Yes (Frame Sequential, Frame Packing, Side-by-Side, Top-Bottom, DLP Link 3D Glasses Supported)

Sync Rates

Horizontal: 15.63 to 135 kHz | Vertical: 24 to 120 Hz

Projection Modes & Offset

Front, Rear, Ceiling Mountable | Vertical Offset: 102.5%

Projection Lens & Optics

Lens Features & Focus

Short-Throw Lens with Auto Focus

Lens Aperture & Focal Length

f/2.53 to 2.73 | f = 10.2 mm to 12.24 mm

Projection Image Size

32" to 200" (1.0 m to 5.0 m)

Throw Distance & Ratio

Short-Throw: 2.0 ft to 12.1 ft (0.6 m to 3.7 m) | Throw Ratio: 0.69 to 0.83:1 (150" @ 8 ft / 2.5 m)

Optical Zoom & Lens Shift

Powered Optical Zoom | No Lens Shift

Keystone Correction

Auto / Manual: Horizontal ±30° | Vertical ±30°

Light Source Specifications

Light Source Engine

Laser Phosphor

Expected Light Source Life

20,000 Hours (Full Brightness)

Audio, Connectivity & Control Specifications

Integrated Audio

Built-in 10 W Speaker (1x 10 W Speaker)

Audio / Video Connections

2x HDMI 2.0 Inputs (HDCP 2.2 Compliant)
1x 3.5mm Mini Audio Output

Control, Data & Wireless Interfaces

1x USB Type-C Port
1x USB Type-A Port
1x USB Type-A Power Output
1x DE-9/DB-9 (RS-232 Control Input)
Wi-Fi Capabilities (via Optional Adapter)

Security Features

Cable Lock Slot, Security Bar

Power, Environmental & Physical Specifications

Input Power Supply

AC 100V – 240V, 50/60 Hz

Power Consumption

Full Brightness: 320 W
Standby Mode: <0.5 W

Operating Environmental Range

Temperature: 0°C to 40°C (32°F to 104°F) | Relative Humidity: 10% to 90%

Certifications

TÜV, UL Certified

Unit Dimensions (W×H×D)

303.5mm x 112.4mm x 234.5mm (11.9" x 4.4" x 9.2")

Net Weight

3.3 kg (7.3 lbs)

Packaging Info

Box: 408.9mm x 335.3mm x 167.6mm (16.1" x 13.2" x 6.6") | Gross Weight: 4.74 kg (10.44 lbs)
