Key Specifications

Type

2-Way Bi-Amp Powered Loudspeaker, Bass Reflex

LF Driver

15" HH Designed Woofer with 3" Voice Coil

HF Driver

1" Compression Driver

Frequency Response

41Hz - 20000Hz (-10dB), 45Hz - 18000Hz (-3dB)

Crossover Frequency

2.5KHz

Coverage

90° x 90°

Max SPL (1m)

128 dB SPL Continuous, 131 dB SPL Peak

Amplifier & Processing Specifications

System Amplifier Power Rating

1400W Peak (Biamp)

Amplifier Type

LF Class D, HF Class A/B

Power Supply

Universal SMPS

Protection

Comprehensive protection and clip free limiting + clip indicator

Controls, Connectivity & Indicators

Controls

2x Channel Gain Controls, Master Volume, Ground Lift, EQ Mode (4 Options)

Input Connectors

2x Balanced Combi XLR/1/4" Jack connectors

Output Connectors

1x Balanced XLR Mix Output

Input Impedance

10K

Signal Indicators

Clip Indicator

Enclosure & Hardware Construction

Enclosure

Robust Black polypropylene cabinet with monitor angle

Grille

Heavy Gauge powder-coated steel, Black with acoustic foam backing

Handles

Two Integrated side handles and one top handle

Rigging & Mounting

4 x M8 Mounting Points; Bottom 35mm Pole Mount Socket with two angles (0° and 7°)

Power Specifications

AC Power Requirements

Universal 100V-240V~ 50/60Hz

Power Inlet

IEC C14 Inlet

Power Consumption

300W Typical

Dimensions & Weight

Unit Dimensions (H×W×D)

699 x 380 x 446mm (27.5" x 15" x 17.6")

Unit Weight

19.6Kg (43.2 lbs)
