Key Specifications

Type

18" Active Subwoofer, Bass reflex

LF Driver

18" HH designed professional bass driver with 3" Voice Coil

Frequency Response

37Hz - *Variable 60-200Hz (-10dB), 42Hz - *Variable 60-200Hz (-3dB)

Crossover Frequency

60-200Hz

Coverage

90° x 90°

Max SPL (1m)

125 dB SPL Continuous, 128 dB SPL Peak

Amplifier & Processing Specifications

System Amplifier Power Rating

1400W Peak

Amplifier Type

Class D

Power Supply

Universal SMPS

Protection

Comprehensive protection and clip free limiting + clip indicator

Controls, Connectivity & Indicators

Controls

Volume, Variable crossover frequency, EQ Shape Switch, Phase reverse switch, Ground lift switch

Input Connectors

2x Balanced XLR

Output Connectors

2x Balanced XLR link outs, 2x Balanced XLR fixed hi-pass outs

Signal Indicators

Clip Indicator, Power

Enclosure & Hardware Construction

Grille

Heavy Gauge powder-coated steel, Black with acoustic foam backing

Handles

Two Integrated side bar handles

Pole Mount

Top 35mm Pole Mount Socket

Power Specifications

AC Power Requirements

User Switchable 110-120V~ or 220-240V~ 50/60Hz

Power Inlet

IEC C14 Inlet

Power Consumption

300W Typical

Dimensions & Weight

Unit Dimensions (H×W×D)

540 x 580 x 592mm (21.3" x 22.8" x 23.3")

Unit Weight

34Kg (75 lbs)
