Key Specifications

Display

No

Channels of I/O

1 Input / 2 Output

Built-In DSP

No

Maximum Sampling Rate

96 kHz / 24-Bit

Number of Microphone Inputs

1

Built-In Microphone

No

Input Level Adjustment

2 × Knob

Signal Processing

Pad

No

Gain / Trim Range

Inputs: 0 to 45 dB

High-Pass Filter

No

Solo / Mute

No

Connectivity

Analog Audio I/O

1 × Combo XLR-1/4" TRS Mic/Line Input
2 × 1/4" TRS Balanced Line Output
1 × 1/4" TRS Headphone Output

Phantom Power

48 V

Digital Audio I/O

No

Host Connection

USB-C

Host Connection Protocol

Not Specified by Manufacturer

USB (Non-Host)

No

Sync I/O

No

Network I/O

No

MIDI I/O

No

Expansion Slots

No

Wireless

No

Performance

Frequency Response

20 Hz to 20 kHz ±1 dB

Maximum Output Level

Monitor Outputs: -6 dBu

Headphone Output Power

24 mW into 32 Ohms
245 mW into 300 Ohms

Impedance

Mic Inputs: 1.3 Kilohms
Hi-Z Inputs: 0.9 Megohm

Dynamic Range

104 dBu

EIN

-128 dBA

Digital Audio

Sample Rates

44.1 to 96 kHz

Sample Rate Conversion

No

Bit Depth

24-Bit

Latency

Zero-Latency Direct Monitoring

Sync Sources

No

Clocking

Internal

Audio Storage & Playback

Media / Memory Card Slot

No

Compatibility

OS Compatibility

macOS 10.11 or Later / Windows 7 or Later

Power

Power Requirements

USB Bus Power

Physical

Dimensions

4.9 × 3.9 × 1.5" / 124 × 100 × 38 mm

Weight

19.8 oz / 561.3 g

Packaging Information

Package Weight

1.155 lb

Box Dimensions (L × W × H)

7 × 5.1 × 2.55"
