Key Specifications

Frequency Range/Response

35 Hz – 160 Hz (-3 dB)

Enclosure Type

Bass-Reflex

Total Output Power

600 W RMS / 1200 W Peak

Amplifier Class

Class-D

Low-Frequency Driver

1 × 15" / 38 cm Woofer (3" / 7.6 cm Voice Coil)

Maximum SPL

126 dB

Digital Signal Processing (DSP)

Voicing Modes, User Settings

EQ & Filters

No

Alignment Delay

No

Audio Inputs

2 × Combo XLR-1/4" TRS Line Input

Audio Outputs

2 × XLR 3-Pin Line Output

Wireless / Network / USB

No

Mobile App Compatible

No

AC Input Power

100–120 VAC, 50/60 Hz
220–240 VAC, 50/60 Hz

AC Power I/O

1 × IEC Input

Current Consumption

3.5 – 7 A

Mounting

1 × 1.38" / 35 mm Pole Socket (Top)

Handles

1 × Each Side

Construction Material

Plywood Cabinet, Metal Grille

Color

Black

Environmental Resistance

No

Dimensions (W × D × H)

24 × 23.9 × 16.7" / 61 × 60.7 × 42.4 cm (Without Casters)

Net Weight

70.5 lb / 32 kg

Package Weight

81.35 lb

Box Dimensions (L × W × H)

28.5 × 27.5 × 20.7"
