Key Specifications

Output Power

1 x 80 W @ 4 Ω / 70 V / 100 V

Frequency Response (-3 dB)

50 Hz - 16000 Hz

Distortion (THD+N) @ 1 kHz

< 0.3 %

Input & Output Section

Total Number of Inputs

5 (4 Mono, 2 Stereo)

Mic+Line Inputs

2 (Euroblock, XLR) with 30 V DC Phantom

Line Inputs

2 (RCA)

Paging Input / Connector

1 / RJ45 (Compatible with BM 3001)

Signal Outputs

2 (RCA)

Power Output Connectors

Euroblock

Processing & Controls

Tone Controls

Yes (Bass/Treble)

High-Pass Filter

150 Hz

Special Functions

VOX, Music on Hold, Chime Tone, Siren

Configuration

DIP switch, Front panel

Standard Compliance & Power

Safety Agency

CE compliant

Operating Voltage

220-240/115 V~ 50/60Hz

Max Power Consumption

160 W

Physical Specifications

Cabinet Material / Color

Metal / Black

Rack Mounting

19", 2U

Dimensions (H x W x D)

88 x 442 x 230 mm / 3.46 x 17.4 x 9.06 inches

Weight

3.77 kg / 8.31 lbs

Shipping Information

Package Dimensions (H x W x D)

200 x 330 x 500 mm / 7.87 x 12.99 x 19.69 inches

Package Weight

5.38 kg / 11.86 lbs
