RCF AM2320
RCF AM2320
|
Key Specifications |
|
|
Output Power |
1 x 320 W @ 4 Ω / 70 V / 100 V |
|
Frequency Response (-3 dB) |
50 Hz - 14000 Hz |
|
Distortion (THD+N) @ 1 kHz |
< 0.3 % |
|
Input & Output Section |
|
|
Total Number of Inputs |
8 (7 Balanced, 2 Unbalanced) |
|
Mic+Line Inputs |
4 (Euroblock, XLR) with 32 V DC Phantom |
|
Line Inputs |
2 (RCA) |
|
Paging Inputs / Connectors |
2 / RJ45 (Compatible with BM 3001) |
|
GPI / Paging Command |
2 General Purpose Inputs / Contact Command |
|
Signal Outputs |
2 (RCA) |
|
Processing & Controls |
|
|
Tone Controls / HPF |
Bass & Treble / 150 Hz High-pass Filter |
|
Special Functions |
VOX, Music on Hold, Chime, Siren, Presence Control |
|
Configuration |
DIP switch, Front panel |
|
Standard Compliance & Power |
|
|
Operating Voltage |
220-240/115 V~ 50/60Hz (Internal Selection) |
|
Max Power Consumption |
600 W |
|
Safety Agency |
CE compliant |
|
Physical Specifications |
|
|
Cabinet Material / Color |
Metal / Black |
|
Rack Mounting |
19", 2U |
|
Dimensions (H x W x D) |
88 x 442 x 230 mm / 3.46 x 17.4 x 9.06 inches |
|
Weight |
5.4 kg / 11.9 lbs |
|
Shipping Information |
|
|
Package Dimensions |
200 x 500 x 330 mm / 7.87 x 19.69 x 12.99 inches |
|
Package Weight |
6 kg / 13.23 lbs |
