Key Specifications

Output Power

1 x 120 W @ 4 Ω / 100 V

Frequency Response (-3 dB)

60 Hz - 15000 Hz

SNR Analog Inputs (A-weighted)

> 85 dB

Distortion (THD+N) @ 1 kHz

< 1.5 %

Crosstalk

< 85 dB

Input & Output Section

Total Number of Inputs

5 (4 Mic+Line, 1 Line)

Mic+Line Connectors

RCA, XLR (with 18 V DC Phantom)

Paging / VOX

XLR Paging Connector / VOX priority on Input 1

General Purpose Inputs (GPI)

1

Signal / Power Outputs

1 RCA Signal Out / Euroblock Power Out

Protections & Controls

Configuration

Front panel (Tone controls included)

Protections

Short circuit, Thermal, DC, Fuses

Cooling

Natural Convection

Power Requirement

Operating Voltage

220-240/115 V~ 50/60Hz (External selection)

Backup Power

24 V DC support

Max Power Consumption

350 W

Physical Specifications

Material / Color

Metal / Black

Rack Mounting

19", 2U

Dimensions (H x W x D)

88 x 431 x 385 mm / 3.46 x 16.97 x 15.16 inches

Weight

7.3 kg / 16.09 lbs

Shipping Information

Package Height / Weight

165 mm (6.5") / 8.5 kg (18.74 lbs)
