Key Specifications

Product / Accessory Type

Bi-Amplified 2-Way Active PA Loudspeaker with Integrated DSP

Enclosure Material & Finish

Polypropylene Cabinet with Black Anti-Scratch Protective Paint

Grille Construction

1.00 mm (0.04") Heavy-Duty Perforated Steel Grille

Integrated Carrying Handles

3 Ergonomic Handles (2x Side Handles, 1x Top Handle)

Pole Mount & Rigging Socket

Standard 35.00 mm (1.38") Pole Mount Socket with Dual-Tilt Angle Selection (0° or 7°)

Acoustic & Electrical Performance Specifications

Amplifier Power Output & Topology

LF Amplifier: 350 W RMS / 700 W Peak (Class-D);
HF Amplifier: 50 W RMS / 100 W Peak (Class-AB);
Total System Power: 400 W Continuous RMS / 800 W Peak

Maximum Peak SPL

134 dB SPL

Frequency Response

50 Hz to 19,000 Hz (19.00 kHz, -10 dB)

Nominal Coverage Dispersion

90° Horizontal x 90° Vertical Constant Directivity Horn

Speaker Component Specifications

Low-Frequency Transducers (Woofer)

1x 304.80 mm (12.00") Woofer with 59.94 mm (2.36") Voice Coil

High-Frequency Transducers (Compression Driver)

1x 34.29 mm (1.35") High-Frequency Compression Driver

Connectivity, Interface & DSP Specifications

Audio Input Interfaces

1x Balanced XLR MIC/Line Input, 2x 1/4" (6.35 mm) Jack Line Inputs, 1x 1/8" (3.5 mm) Mini-Jack Input, 1x Stereo RCA Input Pair

Audio Output Interfaces

1x XLR Thru Output (Direct from Input 1), 1x XLR Balanced Link Output (with Mono / Stereo Selection Switch)

Digital Signal Processing (DSP)

Fully Customizable Integrated DSP Control Architecture

Power & Electrical Specifications

Operating AC Mains Voltage

220 V to 240 VAC, 50 / 60 Hz

Power Consumption

400 W Average / 1,200 W Peak

Fuse Rating

T6.3AL-250V Slow-Blow Fuse

Dimensions & Weight Specifications

Product Dimensions (W×H×D)

345.00 mm x 598.00 mm x 360.00 mm (13.58" x 23.54" x 14.17")

Packaging Dimensions (W×H×D)

375.00 mm x 635.00 mm x 385.00 mm (14.76" x 25.00" x 15.16")

Product Net Weight

15.30 kg (33.73 lbs)
