Key Specifications

System Type

2-Way Full Range, Active Array Element

Amplifier Power

800W Continuous Bi-AMP (650W LF / 150W HF) | 3200W Peak

DSP Processor

32-bit Internal | 24-bit/48kHz AD/DA Conversion

Max SPL @ 1m

121 dB Continuous / 127 dB Peak

Transducers & Acoustic Specs

High Frequency

2 x 1” Celestion Neodymium Compression Drivers (1.75” V.C.)

Low/Mid Frequency

2 x 8” Celestion Neodymium Woofers (Water Resistant)

Frequency Response

70 Hz – 19 kHz (+/-3dB)

Dispersion (-6dB)

110º Horizontal / 10° Vertical

Connectivity & Control

Audio Connectors

XLR In / Link | RJ45 Data In for DSP Control

Power Connectors

Neutrik PowerCON In & Out (Power Linkable)

External Controls

9 Preset EQ | Digital Volume Control | Signal/Clip LEDs

Physical Specifications

Enclosure

18mm Birch Plywood, Water Resistant Coating

Mounting/Rigging

3-point Suspension | Horizontal Trapezoid 2 x 7.5°

Dimensions (HxWxD)

260 x 640 x 470 mm (10.2" x 25.2" x 18.5")

Net Weight

22.5 kg (49.5 lbs)
