Key Specifications

Performance

• Frequency Response: 45 Hz - 20000 Hz
• Max SPL @ 1m: 130 dB
• Coverage Angle: 90° (H) x 60° (V)

Transducers

• Woofer: 1 x 15'', 2.5'' v.c.
• Compression Driver: 1 x 1.0'', 1.75'' v.c.

Processor & Power Section

Amplification

• Total Power: 1400 W Peak
• LF / HF Power: 1000 W / 400 W Peak
• Cooling: Convection

Processing & Controls

• Crossover Frequency: 1600 Hz
• Protections: Thermal, RMS
• Limiter: Soft Limiter
• Controls: Volume, Boost, MIC/Line Switch

Input / Output Section

• Inputs: XLR, Jack (bal/unbal)
• Output: XLR Loop Out
• Input Sensitivity: -2 dBu/+4 dBu (Line), -32 dBu (Mic)
• Power Connection: VDE

Physical Specifications

Construction

• Cabinet: PP Composite with Steel Grille
• Rigging: 2 x M10 points
• Handles: 1 Top, 2 Sides
• Mounting: 35 mm pole mount insert

Size / Weight

• Dimensions: 27.87 x 17.2 x 15.31" / 708 x 437 x 389 mm
• Weight: 43.21 lbs / 19.6 kg

Packaging Info

• Package Weight: 50.71 lb / 23 kg
• Box Dimensions: 29.53 x 19.69 x 17.32"
