Key Specifications

Product / Accessory Type

Bi-Amplified 2-Way Active PA Loudspeaker with Integrated DSP & Bluetooth

Pole Mount & Rigging Socket

Standard 35.00 mm (1.38") Pole Mount Socket (1-Way Fixed Orientation)

Acoustic & Electrical Performance Specifications

Amplifier Power Output & Topology

LF Amplifier: 300 W RMS / 600 W Peak (Class-D);
HF Amplifier: 50 W RMS / 100 W Peak (Class-AB);
Total System Power: 350 W Continuous RMS / 700 W Peak

Maximum Peak SPL

122 dB SPL

Frequency Response

65 Hz to 19,000 Hz (19.00 kHz, -10 dB)

Nominal Coverage Dispersion

90° Horizontal x 60° Vertical

Crossover Frequency

3,200 Hz (3.20 kHz)

Speaker Component Specifications

Low-Frequency Transducers (Woofer)

1x 254.00 mm (10.00") Woofer with 50.80 mm (2.00") Voice Coil

High-Frequency Transducers (Compression Driver)

1x 34.29 mm (1.35") Compression Driver

Connectivity, Interface & DSP Specifications

Wireless Connectivity

Integrated Bluetooth Audio Streaming

Audio Input Interfaces

Combo XLR / 1/4" (6.35 mm) TRS Input, 1/8" (3.5 mm) Mini-Jack Input

Audio Output Interfaces

1x Balanced XLR Line Output

Digital Signal Processing (DSP)

Integrated Onboard DSP Architecture

Dimensions & Weight Specifications

Product Dimensions (W×H×D)

405.00 mm x 615.00 mm x 405.00 mm (15.94" x 24.21" x 15.94")

Product Net Weight

17.00 kg (37.48 lbs)
