Key Specifications

Product / Accessory Type

Bi-Amplified 2-Way Active PA Loudspeaker with Integrated DSP

Enclosure Material & Construction

Heavy-Duty Plywood Cabinet Construction

Grille Construction

1.00 mm (0.04") Steel Grille

Integrated Carrying Handles

2 Integrated Ergonomic Handles

Pole Mount & Rigging Socket

Standard 35.00 mm (1.38") Tripod / Pole Mount Socket

Acoustic & Electrical Performance Specifications

Amplifier Power Output & Topology

LF Amplifier: 200 W RMS / 400 W Peak (Class-D);
HF Amplifier: 50 W RMS / 100 W Peak (Class-AB);
Total System Power: 250 W Continuous RMS / 500 W Peak

Maximum Peak SPL

121 dB SPL

Frequency Response

60 Hz to 18,000 Hz (18.00 kHz)

Speaker Component Specifications

Low-Frequency Transducers (Woofer)

1x 254.00 mm (10.00") Woofer with 50.80 mm (2.00") Voice Coil

High-Frequency Transducers (Compression Driver)

1x 34.29 mm (1.35") Compression Driver with 25.40 mm (1.00") Throat Exit

Connectivity, Interface & DSP Specifications

Audio Input Interfaces

1x Combo XLR / 1/4" (6.35 mm) TRS Multicon Input Jack

Audio Output / Link Interfaces

1x XLR Balanced Link Output (Mono / Stereo Selectable)

Digital Signal Processing (DSP)

Integrated Onboard DSP Architecture

Power & Electrical Specifications

Operating AC Mains Voltage

220 V to 240 VAC, 50 / 60 Hz

Power Consumption

250 W Average / 500 W Peak

Fuse Rating

T6.3AL-250V Slow-Blow Fuse

Dimensions & Weight Specifications

Product Dimensions (W×H×D)

450.00 mm x 535.00 mm x 403.00 mm (17.72" x 21.06" x 15.87")

Product Net Weight

14.08 kg (31.04 lbs)
