Key Specifications

Product / Accessory Type

Bi-Amplified 2-Way Active PA Loudspeaker

Acoustic & Electrical Performance Specifications

Amplifier Power Output & Topology

600 W Continuous RMS / 1,200 W Peak Power (Class-D & Class-AB Bi-Amplified Architecture)

Maximum Peak SPL

136 dB SPL

Frequency Response

50 Hz to 19,000 Hz (19.00 kHz)

Speaker Component Specifications

Low-Frequency Transducers (Woofer)

1x 304.80 mm (12.00") Woofer with 59.94 mm (2.36") Voice Coil

High-Frequency Transducers (Compression Driver)

1x 34.29 mm (1.35") Compression Driver

Connectivity & Interface Specifications

Audio Input Interfaces

2x Combo XLR / 1/4" (6.35 mm) TRS Jacks, 1x 1/8" (3.5 mm) Mini-Jack Input

Audio Output Interfaces

1x XLR Balanced Mix Output

Power & Electrical Specifications

Power Consumption

450 W

Dimensions & Weight Specifications

Product Dimensions (W×H×D)

450.00 mm x 687.00 mm x 465.00 mm (17.72" x 27.05" x 18.31")

Product Net Weight

22.40 kg (49.38 lbs)
