Key Specifications

Product / Accessory Type

Bi-Amplified 2-Way Active PA Loudspeaker

Enclosure Material & Construction

Heavy-Duty Plywood Cabinet Construction

Grille Construction

1.00 mm (0.04") Steel Grille

Integrated Carrying Handles

2 Integrated Ergonomic Handles

Pole Mount & Rigging Socket

Standard 35.00 mm (1.38") Tripod / Pole Mount Socket

Acoustic & Electrical Performance Specifications

Amplifier Power Output & Topology

LF Amplifier: 300 W RMS / 600 W Peak (Class-D);
HF Amplifier: 50 W RMS / 100 W Peak (Class-AB);
Total System Power: 350 W Continuous RMS / 700 W Peak

Maximum Peak SPL

124 dB SPL

Frequency Response

45 Hz to 18,000 Hz (18.00 kHz)

Speaker Component Specifications

Low-Frequency Transducers (Woofer)

1x 381.00 mm (15.00") Woofer with 76.20 mm (3.00") Voice Coil

High-Frequency Transducers (Compression Driver)

1x 34.29 mm (1.35") Compression Driver with 25.40 mm (1.00") Throat Exit

Power & Electrical Specifications

Operating AC Mains Voltage

220 V to 240 VAC, 50 / 60 Hz

Power Consumption

250 W Average / 500 W Peak

Fuse Rating

T6.3AL-250V Slow-Blow Fuse

Dimensions & Weight Specifications

Product Dimensions (W×H×D)

565.00 mm x 665.00 mm x 475.00 mm (22.24" x 26.18" x 18.70")

Product Net Weight

23.24 kg (51.24 lbs)
