Key Specifications

Electrical & Performance

Input Range

0.5 W - 6 W

Attenuation Steps

5 steps (0 dB, -6 dB, -12 dB, -18 dB, OFF)

Terminal Type

Push-in connector

Applicable Cable

600 V Vinyl-insulated (Solid: φ0.8 - φ1.6 mm)

Physical Specifications

Dimensions (with Plate)

70 (W) × 120 (H) × 52.4 (D) mm

Dimensions (Unit only)

41 (W) × 108 (H) × 52.4 (D) mm

Weight

170 g (0.37 lb)

Finish

White (RAL 1013) ABS Resin Plate; Black Case

Environmental & Installation

Operating Temperature

-10 ºC to +50 ºC

Applicable Accessories

Plate: YP-1AF | Box: YS-11A (Optional)

Included Accessories

Plate ×1, Mounting screws (Plate ×2, Box ×2)
