AT-90W

UHF Wideband Multi-function Directional Log Antenna
Dual-mode design supports both transmission and reception in the UHF 470 – 1000 MHz frequency range.
4 – 6 dBi gain enables efficient signal performance over medium to long distances.
Log-periodic directional structure delivers excellent front-to-back ratio and side-lobe suppression, focusing on target signals while minimizing rear interference.
RX Only port features a built-in adjustable booster (0 – 12 dB), powered via bias voltage, to enhance reception sensitivity and stability.
Compatible with MPB-30 antenna booster and AD-12 antenna distributor for extended system coverage and optimized wireless performance.

MIPRO

₱16,000.00 VAT INC.

₱16,000.00

SOLD BY: PIECE/S

Product Code: SKU:MPRO-AT90W-CHN-4366

UHF Wideband Multi-function Directional Log Antenna
Dual-mode design supports both transmission and reception in the UHF 470 – 1000 MHz frequency range.
4 – 6 dBi gain enables efficient signal performance over medium to long distances.
Log-periodic directional structure delivers excellent front-to-back ratio and side-lobe suppression, focusing on target signals while minimizing rear interference.
RX Only port features a built-in adjustable booster (0 – 12 dB), powered via bias voltage, to enhance reception sensitivity and stability.
Compatible with MPB-30 antenna booster and AD-12 antenna distributor for extended system coverage and optimized wireless performance.

Authorized Dealer

Certified Quality Products

After-Sales Support

Secure Payments

Quantity

MIPRO AT-90W

Key Specifications
Model	AT-90W
Name	UHF Wideband Multi-function Directional Log Antenna
Frequency Range	UHF 470–1000 MHz
Antenna Gain	4–6 dBi
Type	Directional
Booster	Built-in 0–12 dB Gain Controllable Booster
Connectors	2 × TNC (TX/RX and RX Only)
Power Supply	DC 8–15 V Bias via RX Only Connector
Impedance	50 Ω
Dimensions	319 × 270 × 25 mm (W × H × D)
Weight	Approx. 480 g
