ATDM-1012DAN

High-quality mic/line inputs with discrete amplifiers and remotely controllable mic preamps
Up to two ES954 Hanging Microphone Arrays (sold separately) can be integrated with the mixer.
Full-matrix mixer with flexible input/output assignments.
USB audio I/O (1 stereo input and 1 stereo output).
Acoustic Echo Cancellation (AEC) and Noise Cancelling (NC) for use with up to 10 mic inputs.
Audio-Technica LINK support for cascading up to 8 ATDM devices.
Dante-compatible model (ATDM-1012DAN) available.
1U design is 19” rack compatible

AUDIO TECHNICA

₱235,000.00 VAT INC.

₱235,000.00

UNIT: PIECE/S

Product Code: SKU:ATCH-ATDM1012-CHN-239

High-quality mic/line inputs with discrete amplifiers and remotely controllable mic preamps
Up to two ES954 Hanging Microphone Arrays (sold separately) can be integrated with the mixer.
Full-matrix mixer with flexible input/output assignments.
USB audio I/O (1 stereo input and 1 stereo output).
Acoustic Echo Cancellation (AEC) and Noise Cancelling (NC) for use with up to 10 mic inputs.
Audio-Technica LINK support for cascading up to 8 ATDM devices.
Dante-compatible model (ATDM-1012DAN) available.
1U design is 19” rack compatible

Authorized Dealer

Certified Quality Products

After-Sales Support

Secure Payments

Quantity

AUDIO TECHNICA ATDM-1012DAN

Key Specifications
Analog Inputs	10 × Mic/Line (Euroblock) + 2 × ST
Analog Outputs	8 × Balanced / 2 × ST Unbalanced
Dynamic Range / SNR	110 dB / 90 dB (A-weighted)
Maximum Gain	64 dB
Digital Connectivity & Networking
Network / Dante	RJ-45 (Dante Primary/Secondary supported)
USB Interface	USB Type-B (24-bit Stereo I/O)
LINK/CHAIN Port	4 × RJ-45 (A/B/C/D Terminals)
Physical Specs
Dimensions (W×D×H)	482.6 × 324.3 × 44 mm (1U Rack)
Weight	3.6 kg (7.9 lbs)
Accessories	Power cable, 22 × Euroblock connectors
