Key Specifications

Display

No

Channels of I/O

2 Inputs / 2 Outputs

Built-In DSP

No

Maximum Sampling Rate

96 kHz / 24-Bit

Number of Microphone Inputs

1

Built-In Microphone

No

Input Level Adjustment

2x Knob

Signal Processing

Pad

No

Gain / Trim Range

Mic / Hi-Z Inputs: 0 to +50 dB
Line Inputs: -20 to +30 dB

High-Pass Filter

No

Solo / Mute

No

Connectivity

Analog Audio I/O

1x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input
1x 1/4" TS Unbalanced Hi-Z Input
1x 1/4" TRS Unbalanced Headphone Output (Front Panel)
2x 1/4" TRS Balanced Monitor Output

Phantom Power

48 V ± 2 V, Selectable On/Off

Digital Audio I/O

No

Host Connection

1x USB-C (Class-Compliant)

Host Connection Protocol

USB 2.0

USB (Non-Host)

No

Sync I/O

No

Network I/O

No

MIDI I/O

No

Expansion Slots

No

Wireless

No

Performance

Frequency Response

Mic Inputs: 20 Hz to 20 kHz ±3 dB
Line Outputs: 20 Hz to 20 kHz ±0.2 dB
Headphone Outputs: 20 Hz to 20 kHz ±0.5 dB

Maximum Input Level

Mic Inputs: +10 dBu (1 kHz, 0.5% THD)
Line Inputs: +19 dB
Hi-Z Inputs: +13 dB

Headphone Output Power

30 mW per Channel into 60 Ohms

Impedance

Mic Inputs: 1.4 Kilohms
Line / Hi-Z Inputs: 750 Kilohms
Line Outputs: 51 Ohms

Dynamic Range

A/D Converters: 90 dB (A-Weighted, 48 kHz Sample Rate)
D/A Converters: 102 dB (A-Weighted, 48 kHz Sample Rate)

SNR

Headphone Outputs: 90 dB (A-Weighted, 1 kHz, Max Gain)

THD+N

Mic Inputs: < 0.004% (Unweighted, 1 kHz, Unity Gain, at +4 dBu)
Line Outputs: < 0.007% (A-Weighted, 1 kHz)
Headphone Outputs: < 0.08% (A-Weighted, 1 kHz, Max Gain)

Digital Audio

Sample Rates

44.1 to 96 kHz

Sample Rate Conversion

No

Bit Depths

24-Bit

Latency

Zero-Latency Direct Monitoring

Sync Sources

Internal

Audio Storage & Playback

Media / Memory Card Slot

No

Compatibility

OS Compatibility

macOS / Windows

RAM Requirements

4 GB

Storage Requirements

200 MB

Mobile Device Compatibility

iPad Pro
iPad
iPad Air
iPad Mini
iPhone
iPod Touch
Android Smartphone
Android Tablet

Required Hardware

USB Cable (Included)
Available USB-A Port

Power

Power Requirements

USB Bus Power

Physical

Dimensions

4.25 x 3.3 x 1.73" / 10.79 x 8.4 x 4.39 cm

Weight

0.5 lb / 0.2 kg

Packaging Info

Package Weight

5.795 lb

Box Dimensions (L x W x H)

14.7 x 13.4 x 6.5"
