Key Specifications

Product / Accessory Type

2-Channel Stereo Integrated Power Amplifier

Speaker Switching & Outputs

A + B Speaker Switching (2-Channel Speaker Output)

Microphone Inputs & Controls

2x Mic Inputs with Level Control & Echo Effect Control

Tone Controls & Equalization

Bass, Middle, Treble, and Balance Controls

Performance & Electrical Specifications

Maximum Output Power

2x 1,000 W Max Power

Frequency Response

20 Hz to 20 kHz

Input Sensitivity

10 mV

Nominal Impedance

8 Ohms

Connectivity Specifications

Audio Inputs & Signal Routing

A & B Inputs, EQ In/Out Loop, Line Audio Out, Subwoofer Bass Out (S. Bass)

Dimensions & Physical Specifications

Product Dimensions (L×W×H)

460 mm x 360 mm x 145 mm (18.11" x 14.17" x 5.71")
