Key Specifications

Max I/O Capacity

64x Input / 42x Output

Number of Analog Input Channels

12

Number of Mic Preamps

12

Number of Analog Output Channels

12

Faders & Level Adjustment

24x 3.9" / 100 mm Fader

Built-In Effects

• Reverb
• Delay
• Chorus
• Flanger
• Phaser

Analog Inputs

12x XLR Balanced Mic/Line Input

Analog Outputs

• 12x XLR Balanced Line Output
• 1x 1/4" TRS Stereo Headphone Output
• 1x 1/8" / 3.5 mm TRS Stereo Headphone Output

Digital I/O

• 2x RJ45 AES3 (Network)
• 1x XLR AES3 Input
• 2x XLR AES3 Output
• 1x etherCON (I/O)

USB I/O

• 1x USB-A 2.0 (2-Track Record, Audio Playback, External Memory)
• 1x USB-A 3.0 / 3.1/3.2 Gen 1 (2-Track Record, Audio Playback, External Memory)

Wireless

No

Rack Mountable

No

Mixer

• Max I/O Capacity: 64x Input / 42x Output
• Number of Analog Input Channels: 12
• Number of Mic Preamps: 12
• Number of Analog Output Channels: 12
• Mix Routing: 12x Stereo FX Return
• Groups: 8x Mute Group, 16x DCA Group
• Presets: No
• Display: 15.6" Touchscreen (x2)
• Faders & Level Adjustment: 24x 3.9" / 100 mm Fader
• Meters: Main Meter: 2x 24-Segment LED

Signal Processing

• Gain/Trim Range: Line/Mic: +5 dB to ±60 dB (in 1 dB Steps)
• Input Pad: -20 dB
• Input Polarity: Normal/Reverse
• Dynamic Processing: Input Channels: Compressor, Gate, Master: Compressor, Limiter
• EQ: No
• Graphic EQ: 28-Band 1/3 Octave, ±12 dB 31 Hz to 16 kHz
• Filters: High-Pass: 20 Hz to 2 kHz, 12 dB/Octave, Low-Pass: 20 Hz to 20 kHz, 12 dB/Octave
• Solo/Mute: Mute, PFL per Input Channel, Bus, Master
• Built-In Effects: Reverb, Delay, Chorus, Flanger, Phaser
• Audio Delay: Adjustable Up to 680 ms
• Automatic Mic Mixing: Yes

Digital Audio

• Sample Rates: AD/DA Conversion: 96 kHz, AES3 Output: 44.1 / 48 / 96 kHz, Stereo Playback: 44.1 / 48 / 96 kHz, Stereo Record: 96 kHz
• Bit Depth: AD/DA Conversion: Up to 24-Bit
• Word Clock Input: 44.1 to 96 kHz

Performance

• Frequency Response: 20 Hz to 30 kHz +0/-0.8 dB
• Max Input Level: Mic/Line Input: +30 dBu
• Analog Dynamic Range: 109 dB
• I/O Impedance: XLR Input: > 4 Kilohms (Pad Out) > 10 Kilohms (Pad In), AES3 Input: 110 Ohms, Line Output: < 75 Ohms, AES3 Output: 110 Kilohms
• SNR: -92 dB
• THD+N: 0.0015% (at +16 dBu Output, 1 kHz 0 dB Gain)
• Signal Generator: Sine, White, Pink, or Band-Pass Noise (Assignable to Any Mix)

Connectivity

• Analog Inputs: 12x XLR Balanced Mic/Line Input
• Analog Outputs: 12x XLR Balanced Line Output, 1x 1/4" TRS Stereo Headphone Output, 1x 1/8" / 3.5 mm TRS Stereo Headphone Output
• Phantom Power: +48 V, Selectable On/Off (Selectable on Individual Inputs)
• Digital I/O: 2x RJ45 AES3 (Network), 1x XLR AES3 Input, 2x XLR AES3 Output, 1x etherCON (I/O)
• MIDI I/O: No
• USB I/O: 1x USB-A 2.0 (2-Track Record, Audio Playback, External Memory), 1x USB-A 3.0 / 3.1/3.2 Gen 1 (2-Track Record, Audio Playback, External Memory)
• Expansion Ports: 2x I/O Card
• Wireless: No
• External Display I/O: No

Recording

• Max Multitrack Recording: 16 Tracks
• Media Support: USB Drive
• File Format Support: WAV

Compatibility

• OS Compatibility: Computer: Windows / macOS, Mobile: Android/iOS

Power

• Input Power: 100 to 240 VAC, 50 / 60 Hz

Physical

• Rack Mountable: No
• Operating Conditions: 32 to 104°F / 0 to 40°C
• Dimensions: 43.3 x 33.5 x 16.7" / 110 x 85.1 x 42.4 cm
• Weight: 75 lb / 34 kg

Packaging Info

• Package Weight: 80 lb
• Box Dimensions (L x W x H): 43 x 32.5 x 16"
