Key Specifications

Aircraft

Takeoff Weight

Approx. 455 g

Dimensions

246×199×55.5 mm (L×W×H)

Max Ascent Speed

2 m/s (Cine mode)
6 m/s (Normal mode)
10 m/s (Sport mode)

Max Descent Speed

1.5 m/s (Cine mode)
6 m/s (Normal mode)
10 m/s (Sport mode)

Max Horizontal Speed

6 m/s (Cine mode)
16 m/s* (Normal mode)
18 m/s (Sport mode)

Max Takeoff Altitude

4500 m

Max Flight Time

Approx. 23 mins

Max Hovering Time

Approx. 22 mins

Max Flight Distance

13.5 km

Max Wind Speed Resistance

10.7 m/s (Level 5)

Max Pitch Angle

48°

Operating Temperature

-10° to 40° C (14° to 104° F)

Internal Storage

42 GB

Class

C1 (EU)

Camera

Image Sensor

Two 1/1.1-Inch Square CMOS Sensors
Effective Pixels per Sensor: 64MP

Lens

FOV: 200°
Format Equivalent: 7.8 mm
Focal Length: 2.5 mm
Aperture: f/1.9
Focus mode: FF
Focus: 1.5 m to ∞

ISO Range

360° Video:
8K@60/50/48fps: 100-12800 (Normal/D-Log M)
8K@30/25/24fps: 100-25600 (Normal), 100-12800 (D-Log M)
6K@60/50/48/30/25/24fps: 100-25600 (Normal), 100-12800 (D-Log M)

360° Photo: 100-6400
Single-Lens Video: 100-12800

Shutter Speed

Video: 1/8000-1/25 s
Photo: 1/8000-1/30 s

Still Photography Mode

Single Shot:
In 360° mode, the resolution is 30 MP* or 120 MP**

Max Image Size

360° Photo: 15520×7760

Photo Format

JPEG/DNG (RAW)

Video Resolution

360° Mode:
8K (2:1): 7680×3840@60/50/48/30/25/24fps
6K (2:1): 6000×3000@60/50/48/30/25/24fps

Single Lens Mode:
4K (4:3)*: 3840×2880@60/50/48/30/25/24fps
4K (16:9): 3840×2160@60/50/48/30/25/24fps
2.7K (4:3)*: 2688×2016@120/100/60/50/48/30/25/24fps
2.7K (16:9): 2688×1512@120/100/60/50/48/30/25/24fps

Video Format

OSV/MP4 (H.265)

Max Video Bitrate

180 Mbps

Color Mode

Normal
D-Log M

EIS

Single Lens Mode:

With RC 2/RC-N2/RC-N3: Supports only RockSteady 3.0

With Goggles 3/N3 paired with RC Motion 3 or FPV Remote Controller 3: Supports a switch between RockSteady 3.0 and HorizonBalancing

Camera FOV

Single Lens Mode:

With RC 2/RC-N2/RC-N3: Natural Wide

With Goggles 3/N3 paired with RC Motion 3 or FPV Remote Controller 3: Standard (Dewarp)/Wide/Natural Wide

Supported File System

exFAT

Gimbal

Stabilization

Single-Axis Mechanical Gimbal (tilt)
360° Virtual Gimbal

Mechanical Range

Tilt: -95° to 173°

Controllable Range

Single-Axis Mechanical Gimbal:
Tilt (With RC 2/RC-N2/RC-N3): -30° to 60°
Tilt (With Goggles 3/N3 paired with RC Motion 3 or FPV Remote Controller 3): -60° to 60°

360° Virtual Gimbal:
Tilt: -180° to 180°
Roll: -180° to 180°

Max Control Speed

Single-Axis Mechanical Gimbal:
Tilt: 100°/s

360° Virtual Gimbal:
Tilt: 100°/s
Roll: 100°/s

Angular Vibration Range

Single-Axis Mechanical Gimbal:
±0.01°

Intelligent Flight Battery

Capacity

≥ 2700 mAh

Weight

Approx. 149 g

Nominal Voltage

14.32 V

Max Charging Voltage

17.2 V

Battery Type

Li-ion

Energy

≥ 38.67 Wh

Discharge Rate

7C (typical)

Charging Temperature

5° to 40° C (41° to 104° F)

Charging Time

With Charging Hub (100W max charging power):
One Battery, From 0% to 100%: Approx. 47 min
One Battery, From 10% to 90%: Approx. 31 min
Three Batteries, From 0% to 100%: Approx. 100 min
Three Batteries, From 10% to 90%: Approx. 70 min

Directly Charging the Drone (65W max charging power):
One Battery, From 0% to 100%: Approx. 73 min
One Battery, From 10% to 90%: Approx. 51 min

Charger

Recommended Charger

Supports DJI 65W Portable Charger and DJI 100W USB-C Power Adapter
With Charging Hub: DJI 100W USB-C Power Adapter is recommended.

Battery Charging Hub

Input

5-20 V, max 5 A

Output (power accumulation)

Max 60 W

Output (charging)

Max 17.2 V

Charging Type

Supports Charging up to Three batteries Simultaneously

Compatibility

DJI Avata 360 Intelligent Flight Battery

Bluetooth

Protocol

Bluetooth 5.4

Operating Frequency

2.400-2.4835 GHz

Transmitter Power (EIRP)

< 10 dBm
