Key Specifications

Speaker

• Active/Passive: Passive
• Number of Included Speakers: 1
• Speaker Configuration: Subwoofer
• Power Handling: For 2 Hours: 500 W RMS, 2000 W Peak; For 100 Hours: 350 W RMS, 1400 W Peak
• Recommended Amplifier Power: 300 W
• Constant Voltage / Transformer Taps: 70 V (300 / 150 / 75 / 38 W or 8 Ohms Bypass), 100 V (300 / 150 / 75 W or 8 Ohms Bypass)
• Impedance: 8 Ohms
• Transformer Wattage: 300 W
• Enclosure Type: Bass-Reflex

Drivers

• LF Driver: 1x 15" / 38.1 cm
• LF Voice Coil: 3" / 7.6 cm

Performance

• Frequency Range: 45 Hz to 2.2 kHz -10 dB
• Frequency Response: 70 Hz to 1.2 kHz ±3 dB
• Maximum SPL: 127 dB (Peak)
• Sensitivity: 94 dB

Connectivity

• Inputs/Outputs: 1x Barrier Strip Speaker Input
• Maximum Wire Gauge: 12 AWG / 2.5 mm

Physical

• Environmental Resistance: Dust/Water-Resistant (IP56)
• Color: Black
• Mounting: 2x M10 Bracket Point (Each Side), 1x M6 Suspension (Rear)
• Dimensions: 19.1 x 19.1 x 18.8" / 48.5 x 48.5 x 47.8 cm
• Weight: 44.5 lb / 20.2 kg, 50.5 lb / 22.9 kg (with Bracket)

Packaging Info

• Package Weight: 59 lb
• Box Dimensions (L x W x H): 23 x 23 x 23"
