Key Specifications

System Acoustic Principle

Line Array Element with Short Transmission Line Back Loading and Acoustic Diffractor

Enclosure Material & Finish

Aluminum Cabinet, High Resistance Water-Based Paint

Flying / Rigging System

Aluminum Fast Link Structure with Dedicated Quick-Release Pins

Transducer Specifications

Transducers

12x 3.5" (88 mm) Neodymium Magnet Woofers (1" / 25 mm Voice Coil)

Cone & Voice Coil Features

Waterproof Cone, Ventilated Voice Coil Design

Acoustic & Performance Specifications

Frequency Response (-6 dB)

90 Hz to 200 Hz (Processed)

Nominal Impedance

8 Ω

Horizontal Coverage Angle

360°

Sensitivity (2.83V @ 1m)

99 dB SPL (Measured @ 4m, Scaled to 1m)

Maximum Peak SPL (@ 1m)

124 dB SPL (Measured @ 4m, Scaled to 1m)

Power Handling Specifications

Continuous AES Power

320 W (Pink Noise Power)

Program Power

640 W

Connectivity & Physical Specifications

Input Connectors

2x Neutrik® Speakon® NL4 (1+/1- Signal IN & LINK; 2+/2- Thru)

Item Dimensions (W×H×D)

Width: 107mm (4.21")
Height: 1166mm (45.91" w/o rigging) / 1212mm (47.72" with rigging)
Depth: 193mm (7.60")

Net Weight

13.2 kg (29.10 lbs w/o rigging) / 15.3 kg (33.73 lbs with rigging)
