Key Specifications

Product Code

39696

Power Output

Both Channels Driven (8 Ω, 1% THD)

630 W Continuous / 650 W Impulsive

Both Channels Driven (4 Ω, 1% THD)

840 W Continuous / 1000 W Impulsive

Bridge Mode (8 Ω, 1% THD)

1680 W Continuous / 2000 W Impulsive

Audio Performance

Input Impedance

20 kΩ Balanced

Signal-to-Noise Ratio (S/N)

>100 dB

Total Harmonic Distortion (THD)

<0.03% (1 kHz, 4 Ω)

Frequency Response

20 Hz – 40 kHz (-6 dB)

Damping Factor

>400

Amplifier Class

Class H (2-Step)

Power

Maximum Power Consumption

2400 VA

Power Supply

220–230 VAC, 50/60 Hz

Protection Features

Protections

Short Circuit, Thermal Protection

Connectivity

Input Connectors

XLR, 1/4" Jack

Output Connectors

Speakon, Binding Post

Physical Specifications

Dimensions (W × H × D)

482 × 88 × 452 mm (19 × 3.5 × 17.8 in)
