Key Specifications

Effect Type

7-Band Graphic Equalizer

Frequency Bands

100 Hz, 200 Hz, 400 Hz, 800 Hz, 1.6 kHz, 3.2 kHz, 6.4 kHz

Boost/Cut Range

±15 dB per band

Input Impedance

500 kΩ

Power & Consumption

DC Power Requirement

9 VDC, 100 mA (Center Negative)

Battery Option

1x 9 V Battery (Not Included)

Operating Current

30 mA

Controls & Connectivity

Level Control

Independent Master Level Slider (±15 dB)

Audio I/O

1/4" TS In / 1/4" TS Out

Switching

Electronic On/Off with Status LED

Physical Specs

Dimensions (WxDxH)

12.3 x 7 x 5.4 cm

Net Weight

0.33 kg (0.73 lb)
