Key Specification

Inputs

2 × Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Inputs
4 × 1/4" TRS Balanced/Unbalanced Line Inputs
2 × 1/4" TRS Balanced/Unbalanced Cue Input
1 × 1/8" / 3.5 mm TRS Unbalanced Stereo Input
1 × 3-Pin XLR Talkback Mic Input

Outputs

2 × 1/4" TRS Balanced/Unbalanced 2-Track Line Outputs
6 × 1/4" TRS Balanced/Unbalanced Monitor Outputs
2 × 1/4" TRS Balanced/Unbalanced Monitor/Line Outputs
2 × 1/4" TRS Unbalanced Headphone Outputs

Footswitch Input

1 × 1/4" TRS

USB I/O

1 × USB 2.0 Type-B

Resolution

24-Bit / 192 kHz

Frequency Response

20 Hz to 20 kHz (±0.5 dB, Unity Gain, +4 dBu Input)

Noise

Mic Inputs to Outputs: < -125 dBu RMS, A-Weighted (150 Ohms Terminated, 22 kHz Bandwidth)
Line Inputs to Outputs: < -90 dBu RMS, Unweighted (150 Ohms Terminated, 22 kHz Bandwidth)

THD + N

<0.01% Unweighted (Unity Gain, 1 kHz at +4 dBu Input, 80 kHz Bandwidth)

Crosstalk

< -60 dB at 1 kHz (Unity Gain, -1 dBFS Input)

Attenuation

Muted: -60 dB
Dim: -20 dB

Maximum Input Level

+22 dBu

Maximum Output Level

+22 dBu

Power Requirements

100 to 240 VAC, 50/60 Hz, 0.75 A via Universal Power Supply

Dimensions

6.8 × 11.9 × 3.2" / 17.3 × 30.2 × 8.1 cm

Weight

4.6 lb / 2.1 kg

Package Weight

6.545 lb

Box Dimensions (L × W × H)

15.4 × 9.55 × 5.65"
