Key Specifications

Product / Accessory Type

Dual-Driver Vented Sub-Bass System

Enclosure Material, Volume & Finish

320.00 L (11.30 cu. ft.) Multi-Laminate Birch Plywood with Textured Black Paint Finish

Grille Construction

Perforated Black Protective Steel Grille

Integrated Carrying Handles

6x Ergonomic Pocket Handles

Hardware, Mobility & Transit Fittings

4x 100.00 mm (4.00") Heavy-Duty Castor Wheels, 2x Transit Lid Clips

Acoustic & Electrical Performance Specifications

Power Handling Capacity

1,500 W AES Continuous / 6,000 W Peak

Recommended System Amplification

iK42 Power Amplifier

System Nominal Sensitivity

105 dB (Half Space)

Maximum Sound Pressure Level (SPL)

136.5 dB Continuous / 142.5 dB Peak (Half Space)

Frequency Response

35 Hz to 150 Hz (±3 dB); -10 dB at 28 Hz

System Nominal Impedance

4 Ω

Active Crossover Frequency Range

80 Hz to 150 Hz Active External Crossover

Speaker Component Specifications

Low-Frequency Transducers (Subwoofers)

2x 460.00 mm (18.00") LF Drivers with 100.00 mm (4.00") Voice Coils

Connectivity & Termination Specifications

Input & Link Connectors

2x Neutrik NL4 SpeakON Connectors

Pin Configurations & Wiring

Low-Frequency (LF+/-): Pins 1+ / 1- and Pins 2+ / 2-

Dimensions & Weight Specifications

Product Dimensions (W×H×D)

561.00 mm x 1,066.00 mm x 780.00 mm (22.09" x 41.97" x 30.71") [Depth with Wheels: 911.00 mm (35.87")]

Product Net Weight

87.00 kg (191.80 lbs)
