Key Specifications

Video & Audio I/O

Video Inputs

• 8x BNC (12G-SDI) Female
• 1x BNC (12G-SDI) Female (Program)

Video Outputs

• 8x BNC (12G-SDI) Female
• 1x BNC (12G-SDI) Female (Loop Output)

Analog Audio Output

1x 1/4" TRS Stereo Analog Female

Embedded Audio

LAN (RJ45)/SDI

Data & Control Interfaces

Expansion Slots

8x SFP Slot (Occupied by 10 Gb/s SMPTE 2110 IP SFP)

Other I/O

1x USB-C 3.0 / 3.1/3.2 Gen 1 (Input)

Format Support

Video Resolution (4:2:2 YUV)

• 4096 x 2160 (up to 60 fps)
• 3840 x 2160 (up to 60 fps)
• 1920 x 1080p/PsF (up to 60 fps)
• 1920 x 1080i (up to 60 fps)
• 1280 x 720 (up to 60 fps)

Standards & Compliance

Video Standard Compliance

SMPTE: ST-2110

HDR Support

Yes

HDCP Support

No

Hardware & OS

Display

2.2" LCD

OS Compatibility

macOS 13 or Later, Windows 10 to 11

Power & Physical

Power I/O

2x IEC C14 (100 to 240 VAC) Input

Rack Form Factor

1 U

Dimensions

19 x 9.22 x 1.74" / 48.3 x 23.42 x 4.42 cm

Weight

8.22 lb / 3.73 kg

Environmental

Operating Conditions

41 to 104°F / 5 to 40°C up to 90% Humidity

Packaging Info

Package Weight

9.035 lb

Box Dimensions (L x W x H)

21.6 x 11.3 x 3.5"
