Key Specifications

Video & Audio I/O

Video I/O

• Input: 1x BNC (12G-SDI) Female
• Output: 1x BNC (12G-SDI) Female

Analog Audio I/O

• Input: 1x XLR 5-Pin Analog Female
• Output: 1x XLR 5-Pin Analog Female

Embedded Audio

LAN (RJ45)/SDI

Data & Control Interfaces

IP/LAN I/O

1x RJ45 (10 GbE) Input/Output

Other I/O

• 1x USB-C (Firmware) Input
• 1x USB-C (Device) Input

Expansion Slots

No

Format Support (4:2:2 YUV via BNC I/O)

4K Format Support

• 4096 x 2160 (up to 60 fps)
• 3840 x 2160 (up to 60 fps)

HD Format Support

• 1920 x 1080p/PsF/i (up to 60 fps)
• 1280 x 720 (up to 60 fps)

Power & Standards

PoE Support

PoE++ 802.3bt

Power I/O

1x Barrel (12 VDC) Input

HDCP Support

No

Physical & Environmental

Operating Conditions

41 to 104°F / 5 to 40°C up to 90% Humidity

Dimensions

5.75 x 2.91 x 1.34" / 14.61 x 7.39 x 3.4 cm

Weight

10.41 oz / 295 g

Packaging Info

Package Weight

1.56 lb

Box Dimensions (L x W x H)

10.4 x 3.3 x 2.5"
