Key Specifications

Imaging & Sensor

Lens Mount

Canon EF (Active mount with AF and Iris support)

Lens Communication

Yes: with Autofocus Support

Image Sensor

Super35 CMOS (23.1 x 12.99 mm)

Effective Resolution

21.2 Megapixel (6144 x 3456)

Image Stabilization

No

Internal Filter Holder

No

Capture Type

Stills & Video

Dynamic Range

13 Stops

ISO Sensitivity

Native: 100 to 25,600

Shutter Type

Electronic Rolling Shutter

Shutter Angle

5° to 360°

Focus Mode

Automatic, Manual Focus

Video Recording Modes (Internal)

Blackmagic RAW (12-bit)

6144 x 3456 @ 23.98/24/25/29.97/50 fps (49 to 483 Mb/s)
6144 x 2560 @ 23.98/24/25/29.97/50/59.94 fps (37 to 359 Mb/s)
5744 x 3024 @ 23.98/24/25/29.97/50/59.94 fps (40 to 395 Mb/s)
4096 x 2160 @ 23.98/24/25/29.97 fps (28 to 163 Mb/s)
3728 x 3104 @ 23.98/24/25/29.97 fps (36 to 265 Mb/s)
2868 x 1512 @ 23.98/24/25/29.97 fps (14 to 101 Mb/s)

Apple ProRes 422

HQ, 422, LT, Proxy
4096 x 2160 up to 60.00 fps
3840 x 2160 up to 60.00 fps
1920 x 1080p up to 120 fps

Slow-Motion Support

Yes

Interfaces & Connectivity

Video Output (USB-C)

Raw 6144 x 3456 @ 23.98/24/25/29.97/50 fps
Raw 5744 x 3024 @ 23.98/24/25/29.97/50/59.94 fps
Raw 6144 x 2560 @ 23.98/24/25/29.97/50/59.94 fps

Video Output (HDMI)

1x HDMI Type A (10-bit 4:2:2 1080p @ 23.98/24/25/29.97/50/59.94 fps)

Audio Input

2x Mini XLR (+48 V Phantom Power)
1x 1/8" (3.5 mm) TRS Stereo Mic/Line Level
Built-In Stereo Microphone

Audio Output

1x 1/8" (3.5 mm) TRS Stereo Headphone

Power I/O

1x Weipu SF610/S2 (12 to 20VDC) Power Input

Other I/O

1x 3.5 mm Timecode Input (Shared with Mic input)
1x USB-C (USB 3.2 / 3.1 Gen 1) Control & Video

Wireless / Apps

Bluetooth (Blackmagic Camera Control App - iOS Only)
Adjust Settings, Remote Control

Global Positioning

No

Physical & Monitoring

Monitor

Tilting 5" LCD Touchscreen (1920 x 1080)

Viewfinder

Optional, Not Included

Media Slots

Slot 1: SD/SDHC/SDXC (UHS-II)
Slot 2: CFast 2.0

Internal Storage

No

Battery Type

Sony L-Series (NP-F570)

Tripod Mount

2x 1/4"-20 Female (Bottom), 1x 1/4"-20 (Top)

Operating Conditions

32 to 104°F / 0 to 40°C (up to 90% Humidity)

Storage Conditions

-4 to 113°F / -20 to 45°C

Construction

Carbon Fiber & Polycarbonate Composite

Dimensions

10.5 x 7.25 x 7" / 26.7 x 18.41 x 17.8 cm

Weight

Body Only: 1.68 kg / 3.71 lb

Packaging Info

Weight: 4.345 lb
Dimensions: 11 x 7 x 6.9"
